Survival Analysis: Zero to Hero Tutorial

This comprehensive tutorial takes you from the foundational concepts of Survival Analysis all the way through advanced model specification, estimation, evaluation, and practical usage within the DataStatPro application. Whether you are encountering survival analysis for the first time or looking to deepen your understanding of time-to-event methods, this guide builds your knowledge systematically from the ground up.

Table of Contents

1. Prerequisites and Background Concepts
2. What is Survival Analysis?
3. The Mathematics Behind Survival Analysis
4. Assumptions of Survival Analysis
5. Types of Survival Analysis Methods
6. Using the Survival Analysis Component
7. Data Structure and Censoring
8. Non-Parametric Methods: Kaplan-Meier Estimation
9. Comparing Survival Curves: Log-Rank and Related Tests
10. Semi-Parametric Methods: Cox Proportional Hazards Model
11. Parametric Survival Models
12. Model Fit and Evaluation
13. Advanced Topics
14. Worked Examples
15. Common Mistakes and How to Avoid Them
16. Troubleshooting
17. Quick Reference Cheat Sheet

1. Prerequisites and Background Concepts

Before diving into survival analysis, it is helpful to be familiar with the following foundational concepts. Each is briefly reviewed below.

1.1 Probability and Probability Distributions

A probability distribution describes the likelihood of all possible outcomes of a random variable. In survival analysis, the primary random variable is time — specifically, the time until a specific event occurs.

The probability density function (PDF) $f(t)$ of a continuous random variable $T$ satisfies:

$f(t) \geq 0 \quad \text{and} \quad \int_0^{\infty} f(t) \, dt = 1$

The cumulative distribution function (CDF) $F(t)$ gives the probability that the event has occurred by time $t$:

$F(t) = P(T \leq t) = \int_0^t f(u) \, du$

1.2 The Complement: Survival Probability

The survival function $S(t)$ is the complement of the CDF — it gives the probability of surviving (not experiencing the event) beyond time $t$:

$S(t) = P(T > t) = 1 - F(t) = \int_t^{\infty} f(u) \, du$

Key properties:

• $S(0) = 1$: At the start, everyone has survived (not yet experienced the event).
• $S(\infty) = 0$: Eventually, all individuals will experience the event (assuming all eventually do).
• $S(t)$ is a non-increasing (monotonically decreasing) function of time.

1.3 Rates and Conditional Probability

A rate measures how frequently an event occurs per unit of time. The conditional probability $P(A \mid B)$ is the probability of event $A$ given that event $B$ has already occurred:

$P(A \mid B) = \frac{P(A \cap B)}{P(B)}$

In survival analysis, we often ask: "Given that an individual has survived until time $t$, what is the probability they experience the event in the next small interval of time?" This is the hazard — one of the central concepts in survival analysis.

1.4 Likelihood and Maximum Likelihood Estimation

The likelihood function $L(\boldsymbol{\theta})$ measures how probable the observed data are, given a set of model parameters $\boldsymbol{\theta}$:

$L(\boldsymbol{\theta}) = \prod_{i=1}^{n} P(\text{observation}_i \mid \boldsymbol{\theta})$

Maximum Likelihood Estimation (MLE) finds the parameter values $\hat{\boldsymbol{\theta}}$ that maximise $L(\boldsymbol{\theta})$ (or equivalently, maximise the log-likelihood $\ell(\boldsymbol{\theta}) = \ln L(\boldsymbol{\theta})$). Most survival models are estimated via MLE or partial MLE.

1.5 The Exponential Distribution — A Simple Survival Model

The exponential distribution is the simplest parametric model for survival data. If $T \sim \text{Exp}(\lambda)$:

$f(t) = \lambda e^{-\lambda t}, \quad t \geq 0$

$S(t) = e^{-\lambda t}$

$F(t) = 1 - e^{-\lambda t}$

Where $\lambda > 0$ is the rate parameter (events per unit time). The mean survival time is $E(T) = 1/\lambda$.

The exponential distribution has the memoryless property: the probability of experiencing the event in the next moment does not depend on how long an individual has already survived. This is a very strong and often unrealistic assumption — more flexible distributions are usually needed.

1.6 Integration and Differentiation (Brief Review)

Survival analysis involves calculus. The key relationships to remember:

$f(t) = \frac{d}{dt}F(t) = -\frac{d}{dt}S(t)$

$S(t) = \int_t^{\infty} f(u) \, du$

These relationships connect the PDF, CDF, and survival function and are used extensively in deriving hazard functions and likelihood contributions.

2. What is Survival Analysis?

2.1 The Core Question

Survival analysis is a branch of statistics that analyses the time until a specific event of interest occurs. The defining questions are:

• How long until the event occurs?
• What is the probability of surviving beyond a given time?
• Do different groups have different survival experiences?
• What factors are associated with shorter or longer time to the event?

Despite the name "survival analysis," the event of interest does not have to be death. It can be any well-defined, non-repeating event:

2.2 What Makes Survival Data Special?

Survival data has two unique characteristics that make it unsuitable for standard regression or t-tests:

1. Censoring: Not all individuals experience the event during the observation period. An individual who is still alive (or event-free) at the end of the study has a censored observation — we know they survived at least until time $t_c$, but we do not know their full survival time.

2. Skewed, positive-only time distributions: Survival times are always positive and often highly right-skewed (many short times, few very long times). Standard methods that assume normality are inappropriate.

These characteristics require special methods — the tools of survival analysis — to produce valid estimates and inferences.

2.3 The Three Central Functions

Every survival analysis revolves around three mathematically related functions. Understanding all three is essential:

These three functions are mathematically equivalent — knowing one fully determines the other two.

2.4 Survival Analysis vs. Standard Regression

3. The Mathematics Behind Survival Analysis

3.1 The Survival Function $S(t)$

The survival function is the probability that the event time $T$ exceeds a specified time $t$:

$S(t) = P(T > t) = 1 - F(t)$

Key mathematical properties:

• $S(0) = 1$ (all subjects start event-free).
• $\lim_{t \to \infty} S(t) = 0$ (all eventually experience the event, assuming no cure).
• $S(t)$ is right-continuous and non-increasing.
• $S(t)$ is a step function when estimated non-parametrically (Kaplan-Meier).

3.2 The Hazard Function $h(t)$

The hazard function (also called the hazard rate or instantaneous failure rate) is the conditional rate at which the event occurs at time $t$, given survival up to $t$:

$h(t) = \lim_{\Delta t \to 0} \frac{P(t \leq T < t + \Delta t \mid T \geq t)}{\Delta t}$

This can be re-expressed using the PDF and survival function:

$h(t) = \frac{f(t)}{S(t)}$

Interpretation: $h(t) \cdot \Delta t \approx P(\text{event in } [t, t+\Delta t] \mid \text{survived to } t)$ for small $\Delta t$.

Key properties of the hazard function:

• $h(t) \geq 0$ for all $t$ (it is a rate, never negative).
• It has no upper bound (unlike a probability).
• It is not a probability — it is a rate (events per unit time among those at risk).
• Different distributions produce different hazard shapes:

3.3 The Cumulative Hazard Function $H(t)$

The cumulative hazard function is the integral of the hazard function over time:

$H(t) = \int_0^t h(u) \, du$

It represents the total accumulated risk of the event from time 0 to time $t$.

3.4 The Fundamental Relationship Between $S(t)$, $h(t)$, and $H(t)$

The three functions are mathematically equivalent through the following relationships:

From hazard to survival:

$S(t) = \exp\left(-\int_0^t h(u) \, du\right) = e^{-H(t)}$

From survival to hazard:

$h(t) = -\frac{d}{dt}\ln S(t) = \frac{f(t)}{S(t)}$

From survival to cumulative hazard:

$H(t) = -\ln S(t)$

From PDF to survival:

$S(t) = \int_t^{\infty} f(u) \, du$

These relationships form the mathematical backbone of survival analysis. Every parametric model defines one of these functions — the others follow automatically.

3.5 The Mean and Median Survival Time

The mean survival time (restricted to time $[0, \tau]$) is the area under the survival curve:

$E(T) = \int_0^{\tau} S(t) \, dt$

The median survival time $t_{0.5}$ is the time at which exactly half of the subjects have experienced the event (i.e., where the survival curve crosses 0.50):

$S(t_{0.5}) = 0.50$

Similarly, the $q$-th quantile of survival is:

$t_q = S^{-1}(1 - q)$

💡 The median is usually preferred over the mean for survival data because the mean is sensitive to a few very long survival times (right tail), and may be undefined if the survival curve never reaches zero (i.e., if not all subjects experience the event).

3.6 The Likelihood Contribution of Censored Observations

A key mathematical challenge in survival analysis is constructing the likelihood function correctly for censored observations. Each observation contributes to the likelihood differently:

Uncensored (event occurred at time $t_i$):

$L_i = f(t_i) = h(t_i) \cdot S(t_i)$

Right-censored (event not observed; known to have survived to $t_i$):

$L_i = S(t_i) = P(T > t_i)$

General likelihood contribution:

$L_i = [h(t_i)]^{\delta_i} \cdot S(t_i)$

Where $\delta_i = 1$ if the event was observed (uncensored) and $\delta_i = 0$ if censored.

Full likelihood for $n$ independent observations:

$L(\boldsymbol{\theta}) = \prod_{i=1}^{n} [h(t_i; \boldsymbol{\theta})]^{\delta_i} \cdot S(t_i; \boldsymbol{\theta})$

Log-likelihood:

$\ell(\boldsymbol{\theta}) = \sum_{i=1}^{n} \left[\delta_i \ln h(t_i; \boldsymbol{\theta}) + \ln S(t_i; \boldsymbol{\theta})\right]$

$= \sum_{i=1}^{n} \left[\delta_i \ln h(t_i; \boldsymbol{\theta}) - H(t_i; \boldsymbol{\theta})\right]$

This formulation correctly accounts for the information provided by both events and censored observations.

3.7 Common Parametric Survival Distributions

Exponential Distribution

$h(t) = \lambda$

$S(t) = e^{-\lambda t}$

$f(t) = \lambda e^{-\lambda t}$

Parameter: $\lambda > 0$ (rate). Mean = $1/\lambda$.

Weibull Distribution

The Weibull is the most widely used parametric survival model due to its flexibility:

$h(t) = \frac{\kappa}{\lambda}\left(\frac{t}{\lambda}\right)^{\kappa - 1}$

$S(t) = \exp\left[-\left(\frac{t}{\lambda}\right)^{\kappa}\right]$

$f(t) = \frac{\kappa}{\lambda}\left(\frac{t}{\lambda}\right)^{\kappa-1}\exp\left[-\left(\frac{t}{\lambda}\right)^{\kappa}\right]$

Parameters: $\lambda > 0$ (scale), $\kappa > 0$ (shape).

• $\kappa = 1$: Reduces to exponential (constant hazard).
• $\kappa > 1$: Increasing hazard (e.g., aging, wear-out).
• $\kappa < 1$: Decreasing hazard (e.g., infant mortality, early failure).

Log-Normal Distribution

$S(t) = 1 - \Phi\left(\frac{\ln t - \mu}{\sigma}\right)$

$h(t) = \frac{\phi\left(\frac{\ln t - \mu}{\sigma}\right)}{\sigma t \left[1 - \Phi\left(\frac{\ln t - \mu}{\sigma}\right)\right]}$

Parameters: $\mu$ (log-scale mean), $\sigma > 0$ (log-scale standard deviation). Produces a hump-shaped hazard (increases then decreases).

Log-Logistic Distribution

$S(t) = \frac{1}{1 + (t/\alpha)^{\gamma}}$

$h(t) = \frac{(\gamma/\alpha)(t/\alpha)^{\gamma-1}}{1 + (t/\alpha)^{\gamma}}$

Parameters: $\alpha > 0$ (scale), $\gamma > 0$ (shape). Produces a hump-shaped hazard when $\gamma > 1$ and a monotone decreasing hazard when $\gamma \leq 1$.

Gompertz Distribution

$h(t) = \lambda e^{\gamma t}$

$S(t) = \exp\left[-\frac{\lambda}{\gamma}(e^{\gamma t} - 1)\right]$

Parameters: $\lambda > 0$ (initial hazard), $\gamma$ (rate of increase). Widely used in actuarial science and demography. Produces a monotonically increasing hazard.

3.8 Summary Table of Parametric Distributions

4. Assumptions of Survival Analysis

4.1 Non-Informative Censoring

The most critical assumption in survival analysis is that censoring is non-informative — the reason an observation is censored must be independent of the true (unobserved) event time.

Examples of non-informative censoring (acceptable):

• Study ends on a fixed calendar date and the participant has not yet experienced the event.
• Participant is still being followed at the time of analysis.
• Participant was lost to follow-up for administrative reasons (e.g., moved country).

Examples of informative censoring (problematic):

• Participants drop out of the study because they are getting sicker (their censoring time is related to their imminent event time).
• A machine is removed from service because it is showing signs of failure.

⚠️ Informative censoring leads to biased estimates of the survival function and hazard. There is no purely statistical remedy — the study design must ensure non-informative censoring.

4.2 Independence of Observations

Each individual's survival time must be independent of all others. This is violated in:

• Clustered data: Patients treated at the same hospital, family members, same litter animals.
• Recurrent events: Multiple events per individual.
• Matched data: Matched pairs or matched sets.

Solutions include frailty models (random effects), marginal models, and conditional models.

4.3 Proportional Hazards (Cox Model)

When using the Cox proportional hazards model (Section 10), the key assumption is that the hazard ratio between any two individuals is constant over time:

$\frac{h_i(t)}{h_j(t)} = \text{constant for all } t$

This means the hazard functions of any two individuals are proportional — they never cross. This is a strong assumption that must be checked (see Section 10.6).

4.4 Correct Parametric Form (Parametric Models)

When using parametric models, the assumed distribution must adequately describe the data. Choosing an incorrect parametric family leads to biased estimates. This must be checked via:

• Graphical diagnostics (log-log plots, hazard plots).
• Formal goodness-of-fit tests.
• AIC/BIC comparison between distributions.

4.5 Consistent Definition of Time Origin and Event

The time origin (time zero) must be consistently and clearly defined for all subjects:

• Date of diagnosis.
• Date of surgery.
• Date of study entry.
• Date of birth.

Similarly, the event must be defined unambiguously — the same event criterion must be applied to all subjects.

⚠️ Inconsistent definitions of time origin or event across subjects will produce biased survival estimates and hazard ratios. This is a design issue, not a statistical one.

4.6 Sufficient Follow-Up and Events

Survival analysis requires:

• Sufficient follow-up time so that a meaningful proportion of subjects experience the event.
• A minimum number of observed events (not total subjects) for reliable estimation:
  • Kaplan-Meier curves: At least 20–30 events for stable estimates.
  • Cox model: At least 10 events per predictor variable (EPV).
  • Parametric models: At least 50–100 events for reliable parameter estimation.

5. Types of Survival Analysis Methods

Survival analysis methods are broadly classified by the degree of parametric assumption they make:

5.1 Non-Parametric Methods

Non-parametric methods make no assumptions about the shape of the survival distribution or hazard function. They let the data speak for themselves.

Advantages: No distributional assumptions; easy to visualise.
Disadvantages: Cannot adjust for multiple covariates simultaneously; no regression coefficients.

5.2 Semi-Parametric Methods

Semi-parametric methods make some parametric assumptions (about the covariate effects) but leave the baseline hazard unspecified.

Advantages: Handles multiple covariates; yields hazard ratios; robust (no distribution assumption).
Disadvantages: Cannot directly predict survival times; hazard ratios assume proportionality.

5.3 Parametric Methods

Parametric methods assume a specific distributional form for the survival times. They are more efficient (better precision) when the assumed distribution is correct.

Advantages: Can predict absolute survival times; extrapolate beyond observed data; more efficient with correct specification.
Disadvantages: Wrong distributional assumption leads to biased results; more sensitive to model misspecification.

5.4 The Method Selection Framework

Subject 1: |—————————————X| Event at t=12 Subject 2: |————————————————————O| Censored at t=24 Subject 3: |——————X| Event at t=6 Subject 4: |————————————————————————————O| Censored at t=36 Subject 5: |—————————————————X| Event at t=18

X = Event observed O = Censored

💡 Always plot the event timeline before analysis. It reveals data quality issues such as negative times, very short follow-up, or suspiciously high censoring proportions.

7.4 The Risk Set

The risk set $\mathcal{R}(t)$ at time $t$ is the set of all subjects who are:

• Still under observation at time $t$ (have not been censored before $t$), AND
• Have not yet experienced the event before time $t$.

The number at risk $n(t) = |\mathcal{R}(t)|$ decreases over time as subjects experience the event or are censored. A number-at-risk table is routinely displayed below Kaplan-Meier plots to communicate how many subjects contribute information at each time point.

8. Non-Parametric Methods: Kaplan-Meier Estimation

8.1 The Kaplan-Meier (Product-Limit) Estimator

The Kaplan-Meier (KM) estimator is the most widely used method for estimating the survival function non-parametrically. It is also called the product-limit estimator because it computes $\hat{S}(t)$ as a product of conditional survival probabilities at each event time.

Let $t_1 < t_2 < \dots < t_k$ be the $k$ distinct ordered event times (only times at which events occur, not censoring times). At each event time $t_j$, let:

• $d_j$ = number of events (deaths) occurring at $t_j$.
• $n_j$ = number of subjects at risk just before $t_j$ (the risk set size).

The conditional probability of the event at $t_j$ (given survival to $t_j$):

$\hat{q}_j = \frac{d_j}{n_j}$

The conditional probability of surviving past $t_j$ (given survival to $t_j$):

$\hat{p}_j = 1 - \hat{q}_j = 1 - \frac{d_j}{n_j} = \frac{n_j - d_j}{n_j}$

The Kaplan-Meier survival estimate at time $t$ is the product of all conditional survival probabilities at event times up to and including $t$:

$\hat{S}(t) = \prod_{j: t_j \leq t} \left(1 - \frac{d_j}{n_j}\right) = \prod_{j: t_j \leq t} \frac{n_j - d_j}{n_j}$

8.2 Worked Computation of the KM Estimator

Suppose $n = 10$ subjects are followed, with the following event/censoring times (sorted):

Key notes:

• The subject censored at $t = 5$ contributed to the risk set at $t = 3$ but not at $t = 7$ (they left before $t = 7$).
• The KM estimate changes only at event times, not at censoring times.
• Between event times, $\hat{S}(t)$ remains constant (step function).
• At $t = 10$, two events occurred simultaneously ($d_j = 2$); $n_j$ is the number at risk just before $t = 10$.

8.3 Confidence Intervals for the KM Estimator

Greenwood's Formula for the variance of $\hat{S}(t)$:

$\widehat{\text{Var}}[\hat{S}(t)] = [\hat{S}(t)]^2 \sum_{j: t_j \leq t} \frac{d_j}{n_j(n_j - d_j)}$

Plain (linear) confidence interval:

$\hat{S}(t) \pm z_{\alpha/2} \sqrt{\widehat{\text{Var}}[\hat{S}(t)]}$

This can produce intervals outside $[0, 1]$ for extreme times. The log-log transformed confidence interval is preferred because it always stays within $[0, 1]$:

Log-log (complementary log-log) transformation:

Let $\hat{U}(t) = \ln[-\ln \hat{S}(t)]$. The variance is approximated by:

$\widehat{\text{Var}}[\hat{U}(t)] = \frac{1}{[\ln \hat{S}(t)]^2} \sum_{j: t_j \leq t} \frac{d_j}{n_j(n_j - d_j)}$

The 95% CI for $U(t)$ is $\hat{U}(t) \pm 1.96 \sqrt{\widehat{\text{Var}}[\hat{U}(t)]}$, which transforms back to a CI for $S(t)$ that stays within $(0, 1)$:

$\left[\hat{S}(t)^{\exp(1.96\sqrt{\widehat{\text{Var}}[\hat{U}(t)]})}, \quad \hat{S}(t)^{\exp(-1.96\sqrt{\widehat{\text{Var}}[\hat{U}(t)]})}\right]$

8.4 The Nelson-Aalen Estimator of the Cumulative Hazard

An alternative non-parametric estimator is the Nelson-Aalen estimator of the cumulative hazard function:

$\hat{H}(t) = \sum_{j: t_j \leq t} \frac{d_j}{n_j}$

The corresponding survival estimate derived from the Nelson-Aalen estimator is:

$\tilde{S}(t) = \exp(-\hat{H}(t))$

The Nelson-Aalen estimator is less biased than the KM estimator in small samples and is particularly useful for:

• Plotting the cumulative hazard to assess parametric distribution fit (see Section 12).
• Computing the baseline cumulative hazard in the Cox model.
• Assessing the proportional hazards assumption graphically.

8.5 Median Survival Time and Confidence Interval

The KM estimate of the median survival time $\hat{t}_{0.5}$ is the smallest time $t$ such that $\hat{S}(t) \leq 0.50$:

$\hat{t}_{0.5} = \inf\{t : \hat{S}(t) \leq 0.50\}$

The 95% confidence interval for the median is computed using the Brookmeyer-Crowley method, which inverts the confidence band for $\hat{S}(t)$ to find the times corresponding to the upper and lower CI bounds for $S(t) = 0.50$.

⚠️ The median survival time is undefined (cannot be estimated) if the KM curve never drops to or below 0.50. This happens when fewer than half the subjects experience the event.

8.6 Reading and Reporting a Kaplan-Meier Curve

A complete KM plot includes:

1. The step function $\hat{S}(t)$ — drops at each event time.
2. Confidence band (typically 95%) shown as a shaded region or dashed lines.
3. Censoring marks — small vertical tick marks at censored times on the survival curve.
4. Number at risk table — shown below the x-axis at selected time points.
5. Median survival time — horizontal dashed line at $S(t) = 0.50$, reading off the x-axis.

9. Comparing Survival Curves: Log-Rank and Related Tests

9.1 The Log-Rank Test

The log-rank test (also called the Mantel-Cox test) is the standard non-parametric test for comparing survival curves between two or more groups. It tests the null hypothesis:

$H_0: S_1(t) = S_2(t) = \dots = S_g(t) \quad \text{for all } t$

$H_1: \text{At least one group has a different survival function}$

At each distinct event time $t_j$ in the combined dataset, the test compares the observed number of events in each group to the expected number under $H_0$ (if all groups had the same survival function).

For each event time $t_j$ and group $g$, the expected number of events under $H_0$ is:

$e_{gj} = n_{gj} \cdot \frac{d_j}{n_j}$

Where:

• $n_{gj}$ = number at risk in group $g$ at time $t_j$.
• $d_j$ = total number of events at $t_j$ across all groups.
• $n_j$ = total number at risk at $t_j$ across all groups.

The log-rank test statistic for two groups ($g = 1, 2$) is:

$\chi^2_{\text{LR}} = \frac{\left(\sum_j (d_{1j} - e_{1j})\right)^2}{\sum_j V_{1j}}$

Where $V_{1j}$ is the hypergeometric variance at event time $t_j$:

$V_{1j} = \frac{n_{1j} \cdot n_{2j} \cdot d_j \cdot (n_j - d_j)}{n_j^2(n_j - 1)}$

Under $H_0$, $\chi^2_{\text{LR}}$ follows approximately a $\chi^2$ distribution with $g - 1$ degrees of freedom (where $g$ is the number of groups).

9.2 Weighted Log-Rank Tests

The log-rank test gives equal weight to all event times. Alternative tests weight earlier or later event times more heavily:

The Fleming-Harrington test with parameters $\rho$ and $\gamma$ is the most flexible:

• $\rho = 0, \gamma = 0$: Log-rank test.
• $\rho = 1, \gamma = 0$: Breslow (Wilcoxon) test.
• $\rho = 0, \gamma = 1$: Emphasises late differences.
• $\rho = 1, \gamma = 1$: Emphasises middle differences.

9.3 Stratified Log-Rank Test

When groups differ on a confounding variable (a variable that affects survival and is unevenly distributed across groups), the stratified log-rank test controls for the confounder by computing the log-rank statistic separately within each stratum and then combining:

$\chi^2_{\text{stratified}} = \frac{\left(\sum_s \sum_j (d_{1js} - e_{1js})\right)^2}{\sum_s \sum_j V_{1js}}$

Where $s$ indexes the strata.

9.4 Interpreting the Log-Rank Test

⚠️ The log-rank test is most powerful when hazard ratios are constant over time (proportional hazards). If survival curves cross (non-proportional hazards), the log-rank test may be underpowered. In this case, use the Fleming-Harrington test with appropriate weights, or report the weighted tests alongside the standard log-rank.

9.5 Pairwise Comparisons After a Significant Log-Rank Test

When comparing $g > 2$ groups and the overall log-rank test is significant, pairwise log-rank tests can identify which specific groups differ. Apply a Bonferroni correction (or similar multiple comparison adjustment) to control the family-wise error rate:

$\alpha^* = \frac{\alpha}{\binom{g}{2}} = \frac{0.05}{g(g-1)/2}$

For example, with $g = 3$ groups: $\alpha^* = 0.05 / 3 = 0.0167$.

10. Semi-Parametric Methods: Cox Proportional Hazards Model

10.1 The Cox Model

The Cox proportional hazards model (Cox, 1972) is the most widely used regression model in survival analysis. It relates the hazard at time $t$ for individual $i$ to their covariate values $\mathbf{x}_i = (x_{i1}, x_{i2}, \dots, x_{ip})^T$:

$h(t \mid \mathbf{x}_i) = h_0(t) \cdot \exp(\beta_1 x_{i1} + \beta_2 x_{i2} + \dots + \beta_p x_{ip})$

Or equivalently:

$h(t \mid \mathbf{x}_i) = h_0(t) \cdot \exp(\boldsymbol{\beta}^T \mathbf{x}_i)$

Where:

• $h_0(t)$ is the baseline hazard function — the hazard for an individual with all covariates equal to zero. It is left completely unspecified (non-parametric) — this is what makes the Cox model semi-parametric.
• $\boldsymbol{\beta} = (\beta_1, \beta_2, \dots, \beta_p)^T$ is the vector of regression coefficients to be estimated.
• $\exp(\boldsymbol{\beta}^T \mathbf{x}_i)$ is the relative risk (risk multiplier) for individual $i$ relative to the baseline.

10.2 The Proportional Hazards Property

The ratio of hazards between any two individuals $i$ and $j$ is constant over time:

$\frac{h(t \mid \mathbf{x}_i)}{h(t \mid \mathbf{x}_j)} = \frac{h_0(t) \exp(\boldsymbol{\beta}^T \mathbf{x}_i)}{h_0(t) \exp(\boldsymbol{\beta}^T \mathbf{x}_j)} = \exp[\boldsymbol{\beta}^T(\mathbf{x}_i - \mathbf{x}_j)]$

The $h_0(t)$ terms cancel — the hazard ratio depends only on the covariate difference, not on time. This is the proportional hazards assumption: hazard functions of any two individuals are proportional to each other (they never cross).

10.3 The Hazard Ratio (HR)

For a single binary covariate $x$ (e.g., treatment vs. control, coded 1 vs. 0):

$\text{HR} = \frac{h(t \mid x = 1)}{h(t \mid x = 0)} = e^{\beta}$

Interpretation of the hazard ratio:

For a continuous covariate $x$: $e^{\beta}$ is the HR for a one-unit increase in $x$, holding all other covariates constant.

The $95\%$ confidence interval for the HR is:

$\left[e^{\hat{\beta} - 1.96 \cdot SE(\hat{\beta})}, \quad e^{\hat{\beta} + 1.96 \cdot SE(\hat{\beta})}\right]$

If the CI does not include 1, the covariate is statistically significant at the 5% level.

10.4 The Partial Likelihood

Because the baseline hazard $h_0(t)$ is left unspecified, standard MLE cannot be applied directly to the Cox model. Instead, Cox (1972) proposed the partial likelihood — a likelihood that eliminates $h_0(t)$ and depends only on $\boldsymbol{\beta}$.

The partial likelihood is constructed by considering, at each event time $t_j$, the probability that it was individual $i_j$ who experienced the event, given that exactly one event occurred at $t_j$ among all individuals at risk:

$L_j(\boldsymbol{\beta}) = \frac{\exp(\boldsymbol{\beta}^T \mathbf{x}_{i_j})}{\sum_{l \in \mathcal{R}(t_j)} \exp(\boldsymbol{\beta}^T \mathbf{x}_l)}$

The full partial likelihood (product over all event times):

$PL(\boldsymbol{\beta}) = \prod_{j=1}^{D} \frac{\exp(\boldsymbol{\beta}^T \mathbf{x}_{i_j})}{\sum_{l \in \mathcal{R}(t_j)} \exp(\boldsymbol{\beta}^T \mathbf{x}_l)}$

The log partial likelihood:

$\ell_{PL}(\boldsymbol{\beta}) = \sum_{j=1}^{D} \left[\boldsymbol{\beta}^T \mathbf{x}_{i_j} - \ln\sum_{l \in \mathcal{R}(t_j)} \exp(\boldsymbol{\beta}^T \mathbf{x}_l)\right]$

Where $D$ is the total number of events.

The coefficient estimates $\hat{\boldsymbol{\beta}}$ are found by maximising $\ell_{PL}$ using iterative numerical methods (e.g., Newton-Raphson).

10.5 Handling Ties

When multiple events occur at the same time (tied event times), the exact partial likelihood becomes computationally intractable. Three commonly used approximations are:

Breslow's approximation (default in most software):

$L_j^{\text{Breslow}} = \frac{\exp(\boldsymbol{\beta}^T \mathbf{s}_j)}{\left[\sum_{l \in \mathcal{R}(t_j)} \exp(\boldsymbol{\beta}^T \mathbf{x}_l)\right]^{d_j}}$

Where $\mathbf{s}_j = \sum_{k \in D_j} \mathbf{x}_k$ is the sum of covariate vectors for all $d_j$ individuals who experienced the event at $t_j$.

Efron's approximation (more accurate with many ties):

$L_j^{\text{Efron}} = \frac{\exp(\boldsymbol{\beta}^T \mathbf{s}_j)}{\prod_{k=1}^{d_j}\left[\sum_{l \in \mathcal{R}(t_j)} \exp(\boldsymbol{\beta}^T \mathbf{x}_l) - \frac{k-1}{d_j}\sum_{l \in D_j} \exp(\boldsymbol{\beta}^T \mathbf{x}_l)\right]}$

Exact (discrete) method: Computes the exact combinatorial probability — accurate but computationally very expensive for large numbers of ties.

💡 Efron's approximation is generally preferred over Breslow's when there are many tied event times. DataStatPro uses Efron's approximation by default.

10.6 Testing the Proportional Hazards Assumption

The proportional hazards (PH) assumption is critical. If violated, hazard ratio estimates are biased and not meaningful. Multiple methods exist to test it:

Method 1: Schoenfeld Residuals Test

The Schoenfeld residual for individual $i$ at event time $t_j$ is the difference between the observed covariate value and its expected value under the model:

$r_{ij} = x_{ij} - \hat{x}_{ij} = x_{ij} - \frac{\sum_{l \in \mathcal{R}(t_j)} x_{lj} \exp(\hat{\boldsymbol{\beta}}^T \mathbf{x}_l)}{\sum_{l \in \mathcal{R}(t_j)} \exp(\hat{\boldsymbol{\beta}}^T \mathbf{x}_l)}$

If PH holds, the Schoenfeld residuals for covariate $j$ should be uncorrelated with time.

The Grambsch-Therneau test formally tests this:

$H_0: \text{Schoenfeld residuals for covariate } j \text{ are uncorrelated with time}$

A significant test ($p < 0.05$) for covariate $j$ indicates a violation of the PH assumption for that covariate.

Graphically: Plot the scaled Schoenfeld residuals against time (or log-time). A flat, horizontal smoothed line supports PH; a clear trend suggests violation.

Method 2: Log-Log Survival Plot

Plot $\ln[-\ln\hat{S}(t)]$ (the complementary log-log of the KM survival estimate) against $\ln t$ for each group. Under proportional hazards, these lines should be approximately parallel:

$\ln H_g(t) = \ln H_0(t) + \boldsymbol{\beta}^T \mathbf{x}_g$

If the log-log curves are parallel, the PH assumption holds for that grouping variable.

Method 3: Time-Covariate Interaction

Add an interaction between each covariate and time (or $\ln t$) to the Cox model:

$h(t \mid \mathbf{x}_i) = h_0(t) \exp[\boldsymbol{\beta}^T \mathbf{x}_i + \boldsymbol{\gamma}^T (\mathbf{x}_i \cdot g(t))]$

Where $g(t)$ is a function of time (e.g., $t$ or $\ln t$). A significant $\hat{\gamma}_j$ indicates that the effect of covariate $j$ changes over time (PH violated).

Remedies When PH is Violated

10.7 Residuals in the Cox Model

Several types of residuals are available for diagnosing the Cox model:

Martingale Residuals:

$\hat{M}_i = \delta_i - \hat{H}_0(t_i)\exp(\hat{\boldsymbol{\beta}}^T \mathbf{x}_i)$

Range from $-\infty$ to $1$. Used to:

• Assess functional form of continuous covariates (plot $\hat{M}$ vs. $x$ — a non-linear pattern suggests a non-linear transformation is needed).
• Identify outliers (very negative values indicate subjects whose event occurred much later than the model predicted).

Deviance Residuals:

$D_i = \text{sign}(\hat{M}_i) \cdot \sqrt{-2[\hat{M}_i + \delta_i \ln(\delta_i - \hat{M}_i)]}$

Approximately normally distributed around 0. Values $|D_i| > 2$ suggest potential outliers.

Score (Schoenfeld) Residuals:

As described in Section 10.6. Used for testing the PH assumption.

Dfbeta Residuals (Influence Diagnostics):

$\widehat{df\beta}_{ij} \approx -r_{ij} \cdot \frac{\widehat{\text{Var}}(\hat{\beta}_j)}{n}$

Estimates how much $\hat{\beta}_j$ would change if observation $i$ were deleted. Large absolute values indicate influential observations.

10.8 The Baseline Survival Function

After estimating $\hat{\boldsymbol{\beta}}$, the baseline survival function $\hat{S}_0(t)$ is estimated using the Breslow estimator:

$\hat{H}_0(t) = \sum_{j: t_j \leq t} \frac{d_j}{\sum_{l \in \mathcal{R}(t_j)} \exp(\hat{\boldsymbol{\beta}}^T \mathbf{x}_l)}$

$\hat{S}_0(t) = \exp(-\hat{H}_0(t))$

The survival function for an individual with covariates $\mathbf{x}$ is then:

$\hat{S}(t \mid \mathbf{x}) = [\hat{S}_0(t)]^{\exp(\hat{\boldsymbol{\beta}}^T \mathbf{x})}$

10.9 The Stratified Cox Model

When a covariate violates the PH assumption, it can be used as a stratifying variable instead of a covariate. The stratified Cox model allows a separate baseline hazard for each stratum $s$, while constraining the regression coefficients to be equal across strata:

$h(t \mid \mathbf{x}_i, s) = h_{0s}(t) \cdot \exp(\boldsymbol{\beta}^T \mathbf{x}_i)$

This approach:

• Relaxes the PH assumption for the stratifying variable.
• Still assumes PH for all included covariates.
• Does not estimate a coefficient for the stratifying variable (it is absorbed into the baseline).

11. Parametric Survival Models

11.1 Parametric Proportional Hazards (PH) Formulation

In parametric PH models, the hazard function is:

$h(t \mid \mathbf{x}_i) = h_0(t; \boldsymbol{\alpha}) \cdot \exp(\boldsymbol{\beta}^T \mathbf{x}_i)$

Where $h_0(t; \boldsymbol{\alpha})$ is a fully specified baseline hazard with parameters $\boldsymbol{\alpha}$ (e.g., Weibull shape parameter $\kappa$). Both $\boldsymbol{\alpha}$ and $\boldsymbol{\beta}$ are estimated simultaneously via MLE.

Weibull PH model (the most common parametric PH model):

$h(t \mid \mathbf{x}_i) = \frac{\kappa}{\lambda}\left(\frac{t}{\lambda}\right)^{\kappa-1} \exp(\boldsymbol{\beta}^T \mathbf{x}_i)$

$S(t \mid \mathbf{x}_i) = \exp\left[-\left(\frac{t}{\lambda}\right)^{\kappa} \exp(\boldsymbol{\beta}^T \mathbf{x}_i)\right]$

11.2 The Accelerated Failure Time (AFT) Model

An alternative parametric formulation is the Accelerated Failure Time (AFT) model, which models the effect of covariates on the log of the survival time directly:

$\ln T_i = \boldsymbol{\beta}^T \mathbf{x}_i + \sigma \epsilon_i$

Or equivalently:

$T_i = \exp(\boldsymbol{\beta}^T \mathbf{x}_i) \cdot T_0$

Where $T_0$ is the baseline survival time and $\sigma$ is a scale parameter.

The survival function in the AFT model:

$S(t \mid \mathbf{x}_i) = S_0\left(\frac{t}{\exp(\boldsymbol{\beta}^T \mathbf{x}_i)}\right)$

The acceleration factor for covariate $x_j$:

$\text{AF}_j = e^{\beta_j}$

Interpretation of AFT coefficients:

💡 The AFT model is more intuitive when covariates do not satisfy the PH assumption. Instead of multiplicative effects on the hazard, it gives multiplicative effects on time itself.

11.3 Relationship Between PH and AFT Formulations

The Weibull model has the unique property of satisfying both the PH and AFT formulations:

Where $\kappa$ is the Weibull shape parameter.

For the exponential, log-normal, log-logistic, and generalised gamma, the AFT formulation is the standard one. For the Weibull and Gompertz, both formulations are available.

11.4 Parametric Model Likelihood

For parametric models, the full MLE log-likelihood for $n$ subjects is:

$\ell(\boldsymbol{\theta}) = \sum_{i=1}^{n} \left[\delta_i \ln h(t_i; \boldsymbol{\theta}) - H(t_i; \boldsymbol{\theta})\right]$

Where $\boldsymbol{\theta} = (\boldsymbol{\alpha}, \boldsymbol{\beta})$ contains all model parameters.

For the Weibull model with shape $\kappa$ and scale $\lambda(\mathbf{x}_i) = \exp(\boldsymbol{\beta}^T\mathbf{x}_i)$:

$\ell = \sum_{i=1}^{n}\left[\delta_i \ln\left(\frac{\kappa}{\lambda_i}\right) + \delta_i(\kappa-1)\ln\left(\frac{t_i}{\lambda_i}\right) - \left(\frac{t_i}{\lambda_i}\right)^{\kappa}\right]$

11.5 Predicting Survival Times From Parametric Models

A major advantage of parametric models over the Cox model is the ability to predict survival times for new individuals.

For an individual with covariates $\mathbf{x}^*$:

Predicted survival function:

$\hat{S}(t \mid \mathbf{x}^*) = \exp\left[-\left(\frac{t}{\exp(\hat{\boldsymbol{\beta}}^T\mathbf{x}^*)}\right)^{\hat{\kappa}}\right] \quad \text{(Weibull)}$

Predicted median survival time:

Solve $\hat{S}(\hat{t}_{0.5} \mid \mathbf{x}^*) = 0.50$:

$\hat{t}_{0.5} = \exp(\hat{\boldsymbol{\beta}}^T\mathbf{x}^*) \cdot [\ln 2]^{1/\hat{\kappa}} \quad \text{(Weibull)}$

Predicted mean survival time (Weibull):

$\hat{E}(T \mid \mathbf{x}^*) = \exp(\hat{\boldsymbol{\beta}}^T\mathbf{x}^*) \cdot \Gamma\left(1 + \frac{1}{\hat{\kappa}}\right)$

Where $\Gamma(\cdot)$ is the gamma function.

12. Model Fit and Evaluation

12.1 Graphical Diagnostics for Parametric Distribution Selection

Before fitting a parametric model, graphical methods help identify which distribution is most appropriate.

Log-Log (Weibull) Plot:

If the Weibull distribution is appropriate, a plot of $\ln[-\ln\hat{S}(t)]$ against $\ln t$ should be approximately linear:

$\ln H(t) = \kappa \ln t - \kappa \ln \lambda$

This is a straight line with slope $\kappa$ and intercept $-\kappa \ln \lambda$.

Log-Normal Plot:

If the log-normal distribution is appropriate, a plot of $\Phi^{-1}(1 - \hat{S}(t))$ against $\ln t$ should be approximately linear.

Log-Logistic Plot:

If the log-logistic distribution is appropriate, a plot of $\ln[(1 - \hat{S}(t))/\hat{S}(t)]$ against $\ln t$ should be approximately linear.

Cumulative Hazard Plot:

Plot $\hat{H}(t)$ (Nelson-Aalen estimate) against $t$ or $\ln t$:

• Linear against $t$ → Exponential.
• Linear against $\ln t$ → Weibull.
• S-shaped → Log-logistic or log-normal.

12.2 AIC and BIC for Model Selection

The AIC and BIC are used to compare parametric models with different distributional assumptions (or different numbers of parameters):

$\text{AIC} = -2\hat{\ell}(\hat{\boldsymbol{\theta}}) + 2q$

$\text{BIC} = -2\hat{\ell}(\hat{\boldsymbol{\theta}}) + q \ln(n^*)$

Where $q$ is the number of estimated parameters and $n^*$ is the number of events (not total observations, in some implementations).

Lower AIC/BIC indicates a better-fitting, more parsimonious model.

💡 AIC and BIC can compare models from different distributional families (e.g., Weibull vs. log-normal) as long as they use the same outcome and data — unlike the $\Delta\chi^2$ test, which requires nested models.

12.3 Likelihood Ratio Test for Nested Models

When comparing nested parametric models (one model is a restricted version of another), the likelihood ratio test (LRT) formally tests whether the additional parameters significantly improve fit:

$\Lambda = -2[\ell(\hat{\boldsymbol{\theta}}_{\text{restricted}}) - \ell(\hat{\boldsymbol{\theta}}_{\text{full}})]$

Under $H_0$, $\Lambda$ follows a $\chi^2$ distribution with $\Delta q$ degrees of freedom ($\Delta q$ = number of additional parameters in the full model).

Example: Testing whether the Weibull model fits significantly better than the exponential (which is a special case with $\kappa = 1$):

$\Lambda = -2(\ell_{\text{Exp}} - \ell_{\text{Weibull}}) \sim \chi^2(1)$

12.4 Cox-Snell Residuals for Overall Fit

The Cox-Snell residuals can be used to assess the overall fit of any survival model (Cox or parametric):

$\hat{r}_i^{CS} = \hat{H}(t_i \mid \mathbf{x}_i) = -\ln \hat{S}(t_i \mid \mathbf{x}_i)$

If the model fits well, the Cox-Snell residuals should follow a unit exponential distribution (i.e., $\hat{H}(\hat{r}_i^{CS}) \approx \hat{r}_i^{CS}$).

Check: Plot the Nelson-Aalen estimate of the cumulative hazard of the Cox-Snell residuals against the residuals themselves. If the model fits well, this plot should fall approximately on the line $y = x$ (45-degree line).

12.5 Concordance Index (C-statistic)

The concordance index (C-index) measures the discriminative ability of a survival model — how well it ranks individuals by their predicted risk. It is the survival analysis analogue of the AUC for binary outcomes:

$C = \frac{\sum_{i < j} \mathbf{1}[t_i < t_j] \cdot \mathbf{1}[\hat{\eta}_i > \hat{\eta}_j] \cdot \delta_i}{\sum_{i < j} \mathbf{1}[t_i < t_j] \cdot \delta_i}$

Where $\hat{\eta}_i = \hat{\boldsymbol{\beta}}^T \mathbf{x}_i$ is the predicted linear predictor (risk score) for individual $i$.

12.6 The Global Likelihood Ratio Test (Cox Model)

For the Cox model, three omnibus tests assess whether any covariate is significantly associated with survival:

Likelihood Ratio (LR) Test:

$\chi^2_{LR} = -2[\ell_{PL}(\mathbf{0}) - \ell_{PL}(\hat{\boldsymbol{\beta}})] \sim \chi^2(p)$

Wald Test:

$\chi^2_W = \hat{\boldsymbol{\beta}}^T [\widehat{\text{Var}}(\hat{\boldsymbol{\beta}})]^{-1} \hat{\boldsymbol{\beta}} \sim \chi^2(p)$

Score (Log-Rank) Test:

$\chi^2_S = \mathbf{U}(\mathbf{0})^T [\mathbf{I}(\mathbf{0})]^{-1} \mathbf{U}(\mathbf{0}) \sim \chi^2(p)$

Where $\mathbf{U}(\mathbf{0})$ is the score vector and $\mathbf{I}(\mathbf{0})$ is the information matrix, both evaluated at $\boldsymbol{\beta} = \mathbf{0}$.

All three tests are asymptotically equivalent. The LR test is generally considered the most reliable in finite samples.

12.7 Calibration: Observed vs. Predicted Survival

Calibration assesses whether the predicted survival probabilities match the observed survival rates. A well-calibrated model should show that, among individuals predicted to have (for example) a 70% chance of surviving 5 years, approximately 70% actually do survive 5 years.

The Hosmer-Lemeshow-style calibration test for survival groups subjects by predicted risk (deciles) and compares observed and expected survival in each group. Formally, the D'Agostino-Nam test extends this to survival data:

$\chi^2_{HLS} = \sum_{g=1}^G \frac{(O_g - E_g)^2}{E_g(1 - E_g/n_g)} \sim \chi^2(G-2)$

13. Advanced Topics

13.1 Time-Varying Covariates

In some studies, covariate values change during follow-up (e.g., treatment dose, blood pressure, smoking status). These are time-varying covariates and must be incorporated into the Cox model using a counting process data format.

In the counting process format, each period of follow-up during which a covariate value is constant becomes a separate row:

The counting process Cox model for time-varying covariates $\mathbf{x}_i(t)$:

$h(t \mid \mathbf{x}_i(t)) = h_0(t) \exp(\boldsymbol{\beta}^T \mathbf{x}_i(t))$

⚠️ Careful: Internal time-varying covariates (values affected by the individual's own disease process — e.g., a biomarker) can introduce bias. Only external covariates (unaffected by the subject's status) can be safely included as time-varying covariates without special considerations.

13.2 Frailty Models (Random Effects for Survival)

Frailty models extend the Cox model to account for unobserved heterogeneity among subjects or clustering (e.g., patients within hospitals, multiple events per subject). A random frailty term $Z_i$ is introduced:

$h(t \mid \mathbf{x}_i, Z_i) = Z_i \cdot h_0(t) \exp(\boldsymbol{\beta}^T \mathbf{x}_i)$

Where $Z_i$ is a random variable (the "frailty") assumed to follow a specific distribution:

• Gamma frailty (most common): $Z_i \sim \text{Gamma}(1/\theta, 1/\theta)$, with $\text{Var}(Z_i) = \theta$. The marginal survival function has a closed form.
• Log-normal frailty: $\ln Z_i \sim \mathcal{N}(0, \sigma^2)$.
• Inverse-Gaussian frailty.
